MODEL 2005

Vector Peristaltic Pump

Design Features

The best solution for difficult process fluids

  • Dry pump cavity
  • Self-priming operation
  • Runs dry without damage
  • Complete isolation of fluid pumped
  • Heavy-duty roller bearings
  • Variety of pump configurations, flows, and pressure ratings
  • No seals, cups or packing to leak or wear
  • Reversible flow
  • Low maintenance

Vector Pumps Resources

Model 2005 - Datasheets
Datasheets
Model 2005
(Performance, Dimensions, Options, Ordering Information)
Pump Selection
Design Considerations

Model 2005 - Specifications
Fluid Characteristics
Viscosity:15,000 cps max.
Liquid Temperature: 180°F (82°C) max.
Solid Size: (see Selection Guide)
Fiber Length:1-1/4 inch (31.7 mm) max.
Specifications
Discharge Pressure:50 psig (3.4 bar) max.
Suction Lift:16.5 ft. (5 m)
Suction Pressure:25 psig (1.7 bar) max.
Horsepower:*3/4 max.
Hose Size:25 x 43 x 860 mm
Displacement:0.085 gal/rev (0.032 l/rev)
Weight (pump only):40 lbs. (18 kg)
Weight (with drive):83 lbs. (38 kg)

* Pumps are shaft driven and require a gearbox and motor.

Vector Pumps 2000-3000 Manuals
Vector Peristaltic Pump Installation and Operation Models 2002-2007
Entire Manual
Vector Peristaltic Pump Installation and Operation Models 2008-2010
Entire Manual
Vector Peristaltic Pump Installation and Operation Models 3005
Entire Manual
Hose Data

Vector pumps isolate the fluid being pumped into a single, durable hose so they can handle tough fluids.

Designed by the process industry for the process industry

When we say “Simply Built to Last”, we mean it!
